Environmental Friendly Chemical Anchor Adhesive Shrinkage Proof Suitable For Indoor
420ml 2:1 Two Component Chemcial Anchor Adhesive For Thread Rods
Chemical anchor adhesive, epoxy injection mortar, Chemical fixing glue,
Chemical anchoring system used for anchoring and rebar connections in concrete.
Item #: FixingChor142
Capacity: 420ml
Materials: Epoxy
Mixing Ratio: 2:1
From rebar dwelling on a high-traffic infrastructure retrofit project to DIY projects, Xinchor offers a wide variety of adhesive anchoring products to meet your need.
Our strong, versatile epoxy-based adhesives are ideal for anchoring threaded rod, rebar and smooth dowels in an assortment of base materials. And our acrylic formulations deliver consistent performance for high-strength anchor grouting in a wide range of weather conditions, curing fast even in water-saturated concrete.
Ideal for anchoring threaded rod, rebar and smooth in a variety of base materials, epoxy-based anchoring adhesives offer strength and versatility across a wide variety of applications. Xinchor Fixingchor series epoxy adhesives meet or are rigorously tested to meet 2009 IBC requirements for both cracked and uncracked concrete applications. As you would expect, we offers all the high-strength dispensing tools and other important accessories to increase productivity on any project.
A two-component, high strength adhesive anchoring system. The system includes injection adhesive in plastic cartridges, mixing nozzles, dispensing tools and hole cleaning equipment. is designed for bonding threaded rod and reinforcing bar hardware into drilled holes in concrete base and solid masonry materials.
Pure Epoxy 3:1 resin is a high performance, two components pure epoxy resin system. Applied in one
single action this resin will produce a high performance, strong fixing with exceptionally high chemical resistance.
Solvent-free, epoxy resin based, two part high performance anchoring adhesive.
A two component chemical anchoring injection system.
A formulation derived from a special resin blend, with high bond strength,
developed principally to anchor threaded rods into concrete. Used widely for
installations in extremely cold temperature situations.
Xinchor FixingChor injection system is a composite mortar based on epoxy resin. The mortar consists of 2 components, which are mixed in the static mixer to form a perfectly mixed mortar mass and can therefore harden.
Xinchor FixingChor Series are available in various packaging solutions. From small 360ml to 650ml cartridge for processing large quantities of mortar. All cartridges are side-by-side cartridges and must therefore be pressed out with a dispenser.
Xinchor FixingChor composite mortar is ideal for subsequent reinforcement connections (rebar) as well as highly stressed fastenings in concrete - regardless of whether cracked or non-cracked. In particular, large drilling diameters and / or large anchoring depths can be implemented very well due to the long processing time. The extensive evaluation in accordance with the latest standards makes it possible to solve almost all fastening-related problems.
| Testing project | Condition | Index |
| Gel Performance (According to China National Standard GB50728-2011) |
| Splitting Tensile Strength (MPa) | Under (23±2)℃,(50±5)%RH, tested by loading speed of 2mm/min | ≥8.5 |
| Flexural Strength (MPa) | ≥50 (no fragment damage) |
| Compressive Strength (MPa) | ≥60 |
| Bonding Capacity (According to China National Standard GB50728-2011) |
| Steel-Steel Tensile Shear Strength (MPa) | (23±2)℃,(50±5)%RH | ≥10 |
| Bonding strength of Ribbed steel bar (or screw) with concrete under constrain drawing condition | (23±2)℃ (50±5)%RH | C30,Ф25,L=150mm | ≥11 |
| C60,Ф25,L=150mm | ≥17 |
| Steel-Steel T-peeling strength (mm) | (23±2)℃,(50±5)%RH | ≤25 |
| Non-volatile content | (105±2)℃,(180±5)min | ≥99% |
| Ageing resistance to heat and humidity 90d |
| Reduction rate of tensile strength | Under normal room temperature | ≤12% |
| (According to China National Standard JGJ145-2013) |
| Tensile Strength (after high temperature welding) | Dia12 Grade II steel, C30 concrete Hole dia.16mm, Depth: 150mm | 55.1N, 57.0N, 54.8N |
Approved for anchorings in
Concrete, cracked and non-cracked Applications
Rebar planting in concrete structures.
Railway or express way modification works
Structure reinforcement
Curtain wall installing
Bridge modification works
Keel fixing in out wall
ATTENTION
-If the gelling time expires, please use a new static mixer.
-Do not cut or shorten nozzles.
-It can be used again in the future by replacing the static mixer.
-Please ensure hole is properly cleaned. Hole may be damp but must be free from water.
-Do not install anchors when substrate temperature is less than 0°C.
-Do not install anchors when the temperature is less than 10°C.
-If the cartridge is not finished, please clean the opening, then put the plug back and cap tightly.
-At temperatures below 10°C should be warmed or stored in temperatures
of 10-30°C for 24hours prior to use to improve product flow and cure.
